6GK5793-8DL00-0AA0 ANT793-8DL antenna, IWLAN, railway app., directivity, 5GHz 14dBi, N-female, IP66

ANT793-8DL IWLAN antenna vertically-horizontally polarized with strong directional effect incl. 2x N-female socket; 14 dBi; IP66 (-45-+70 °C), 5 GHz; suitable for railway applications; Wi-Fi compliance and Observe national approvals; Mounting on wall or mast; compact instructions as hard copy German/English; scope of delivery: 1x ANT793-8DL, 1x mounting aid for alignment . SCALANCEAntennaAntenna ANT793-8DLIdeally suitable for space-saving wall or mast mounting along a rail line and in tunnels. Selective coverage of warehouse/high-bay warehouse aisles. Communication between buildings over long distances. The antenna is connected to access points or clients via an IWLAN antenna connection cable.Enhanced data throughput and increased reliability of the wireless connection through selective use of multiple path propagation. Two data streams can be transmitted simultaneously. –High passive amplifications and long ranges (bridging long distances) thanks to the concentration of the radio field and the small opening angle. The radio field is concentrated into a tight cone. Investment security through compliance with the globally recognized IEEE 802.11 standard. Cost-effective connection to devices in remote, difficult-to-access or aggressive environments.
